LG9600 Plus Real-Time PCR Instruments
Request a price
96-seat plate;
Number of channels: 4 or 5
Detection (F1: FAM, SYBR GREEN, F2: HEX, VIC, TET, JOE, CY3, NED, TAMRA, F3: ROX, TEXAS-RED, F4: CY5)
No crosstalk between the different channels, unique bottom detection: up to 5 µL reaction volume;
Sample capacity: 96 x 0.2 ml PCR plate, 12 x 8 strip tubes, 96 x 0.2 ml individual PCR tubes;
Reaction mixture volume: 5-100 µl;
Dynamic range: 1-10^10 copies;
Emission: 500-800 nm, excitation (LED): 300-800 nm;
Gradient temperature range. 1-36ºC
Module temperature range: 4-105ºC
Running/cooling speed: 5.0ºC/s (max)
Temperature control accuracy: ≤ ±0.1ºC
Temperature uniformity: ≤ ±0.3ºC
Roof heating range: 30-110ºC (Adjustable, standard: 105ºC and automatic heated roof)
Fluorescence detection repeatability: 5%
Programming: Max. 20 episodes in each program, max. 99 cycles
Scan time: 5.5 sec Scan mode: entire plate or selected row
Special functions: Absolute quantitative automatic determination, Relative quantification, SNP Analysis, Melting curve genotyping, HRM, Gradient, multi-channel crosstalk calibration, Background correction, Automatic amplification
Operating system: Microsoft: Windows7/Windows8.1/ Windows10 Software: excel2000/2002/2003/2007/2012
Minimum PC configuration: RAM: 512M, hardware space: 10GB CPU: Pentium 4 virtual memory≥1000MB
100-240V 50/60Hz 600W
Dimensions: 410*386*352mm
Ports: USB adapter, RS232 adapter and Bluetooth adapter
Certificates: Ferrotec Peltier/CE/EMC/RoHS2.0/PICC
Product quality liability insurance
