301.LFC5
5 ml
low
29 x 19 mm
pc
"Diameter: 29 mm.
Height: 15 mm.
Volume: 5 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
"Diameter: 29 mm.
Height: 15 mm.
Volume: 5 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
301.LFC10
10 ml
low
38 x 19 mm
pc
Crucible made of high-purity quartz
Crucible made of high-purity quartz
301.TFC10
10 ml
tall
27 x 32 mm
pc
"transparent. Diameter: 27 mm. Height: 32 mm. Volume: 10 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance. Usable: up to 1,730 °C."
"transparent. Diameter: 27 mm. Height: 32 mm. Volume: 10 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance. Usable: up to 1,730 °C."
301.LFC15
15 ml
low
41 x 25 mm
pc
"transparent. Diameter: 41 mm. Height: 25 mm. Volume: 15 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance. Usable: up to 1,730 °C."
"transparent. Diameter: 41 mm. Height: 25 mm. Volume: 15 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance. Usable: up to 1,730 °C."
301.TFC15
15 ml
tall
32 x 33 mm
pc
"transparent. Diameter: 32 mm. Height: 33 mm. Volume: 15 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance. Usable: up to 1,730 °C."
"transparent. Diameter: 32 mm. Height: 33 mm. Volume: 15 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance. Usable: up to 1,730 °C."
301.TFC20
20 ml
tall
35 x 38 mm
pc
opaque. Diameter: 35 mm. Height: 38 mm. Volume: 20 ml.
Material: high purity quartz (>99,8% SO2). Low thermal expansion, good chemical resistance. Max. applicable temperature: 1730 °C.
opaque. Diameter: 35 mm. Height: 38 mm. Volume: 20 ml.
Material: high purity quartz (>99,8% SO2). Low thermal expansion, good chemical resistance. Max. applicable temperature: 1730 °C.
301.LFC25
25 ml
low
47 x 28 mm
pc
"transparent""fused"" quartz.
Diameter: 47 mm.
Height: 28 mm.
Volume: 25 ml.
Material: high purity (>99.8% SO2), bulk quartz.
Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
"transparent""fused"" quartz.
Diameter: 47 mm.
Height: 28 mm.
Volume: 25 ml.
Material: high purity (>99.8% SO2), bulk quartz.
Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
301.TFC30
30 ml
tall
43 x 39 mm
pc
"transparent ""fused"" quartz.
Outer diameter at the top: 45 mm.
Height: 41 mm.
Wall thickness: 2 mm.
At the bottom, the flat part is approx. 18 mm.
Volume: 30 ml.
Material: high purity (>99.8% SO2), bulk quartz.
Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
"transparent ""fused"" quartz.
Outer diameter at the top: 45 mm.
Height: 41 mm.
Wall thickness: 2 mm.
At the bottom, the flat part is approx. 18 mm.
Volume: 30 ml.
Material: high purity (>99.8% SO2), bulk quartz.
Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
301.LFC50
50 ml
low
57 x 37 mm
pc
"Diameter: 57 mm.
Height: 37 mm.
Volume: 50 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
"Diameter: 57 mm.
Height: 37 mm.
Volume: 50 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
301.TFC50
50 ml
tall
51 x 51 mm
pc
opaque. Diameter: 51 mm. Height: 51 mm. Volume: 50 ml.
Material: high purity quartz (>99,8% SO2). Low thermal expansion, good chemical resistance. Max. applicable temperature: 1730 °C.
opaque. Diameter: 51 mm. Height: 51 mm. Volume: 50 ml.
Material: high purity quartz (>99,8% SO2). Low thermal expansion, good chemical resistance. Max. applicable temperature: 1730 °C.
301.LFC80
80 ml
low
67 x 45 mm
pc
"transparent. Diameter: 67 mm. Height: 45 mm. Volume: 80 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance. Usable: up to 1,730 °C."
"transparent. Diameter: 67 mm. Height: 45 mm. Volume: 80 ml.
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance. Usable: up to 1,730 °C."
301.LFC100
100 ml
low
71 x 50 mm
pc
"transparent material.
Diameter: 71 mm.
Height: 50 mm.
Volume: 100 ml.
Material: high purity (>99.8% SO2), bulk quartz.
Very low coefficient of thermal expansion and excellent chemical resistance. Usable: up to 1,730 °C."
"transparent material.
Diameter: 71 mm.
Height: 50 mm.
Volume: 100 ml.
Material: high purity (>99.8% SO2), bulk quartz.
Very low coefficient of thermal expansion and excellent chemical resistance. Usable: up to 1,730 °C."
301.LFC150
150 ml
low
82 x 51 mm
pc
"Diameter: 82 mm
Height: 51 mm
Volume: 150 ml
Weight: approx. 52-58 g
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
"Diameter: 82 mm
Height: 51 mm
Volume: 150 ml
Weight: approx. 52-58 g
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
301.TFC200
200 ml
tall
76 x 81mm
pc
"Upper diameter: 76 mm
Bottom diameter 40 mm
Height: 81 mm
Volume: 200 ml
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
"Upper diameter: 76 mm
Bottom diameter 40 mm
Height: 81 mm
Volume: 200 ml
Material: high purity (>99.8% SO2), bulk quartz. Very low coefficient of thermal expansion and excellent chemical resistance.
Usable: up to 1,730 °C."
