ALPHA-OPTIKA biological microscopes for simpler applications and schools

Alpha Optika

Request a price

ALPHA-OPTIKA biological microscopes for simpler applications and e.g. can also be used in education. The common features of the B-150 series are the monocular head, which can be tilted 30º and rotated 360º. Each device has LED lighting. The package includes a dust cover and a network cable.

Technical data of ALPHA-OPTIKA biological microscopes:

Type	B-151	B-153	B-155	B-157	B-159
Head:	monocular	monocular	monocular	binocular	binocular
Eyepiece:	10 x (Ø 180 mm)	10 x (Ø 180 mm)	10 x (Ø 180 mm)	10 x (Ø 180 mm)	10 x (Ø 180 mm)
Objective:	Achromat 4x, 10x 40x	Achromat 4x, 10x, 40x, 60x	Achromat 4x, 10x, 40x, 100x	Achromat 4x, 10x, 40x, 60x	Achromat DIN 4x, 10x, 40x, 100x
Focusing:	Rough and fine	It separates coarse and fine from each other	Coaxial coarse and fine	Coaxial coarse and fine	Coaxial coarse and fine
Slide holder:	125x120mm	125x116mm	125x116mm	125x116mm	125x116mm
Slide holder movement:	-	76x30mm	76x30mm	76x30mm	76x30mm
Condenser:	with aperture and filter holder NA 0.6	with aperture and filter holder NA 1.25	with aperture and filter holder NA 1.25	with aperture and filter holder NA 1.25	with aperture and filter holder NA 1.25
Illumination:	1W LED	1W LED, adjustable	1W LED, adjustable	1W LED, adjustable	1W LED, adjustable


code

Name

net price

amount

in stock

112.B151

B-151 monocular biological microscope

Request a price

"Monocular head, tilted 30? and can be rotated 360? - WF10X / 18mm wide field eyepiece - Achromat lenses DIN 4X / 0.10, 10X / 0.25, 40X / 0.65 / spring, - 125x116mm specimen table, with specimen clamps - Focusing system, coaxial with coarse and fine adjustment - 1.25 N.A. condenser, with aperture and filter holder - 1W LED lighting, with adjustable brightness, with mains cable - Dust cover"

112.B153

B-153 monocular biological microscope

Request a price

"Monocular head, tilted 30? and can be rotated 360? - WF10X / 18mm wide field eyepiece - Achromat lenses DIN 4X / 0.10, 10X / 0.25, 40X / 0.65 / spring, 60X / 0.8 / spring - 125x116mm specimen stage, with XY specimen mover, movement range 76x30mm - Focusing system, coaxial with coarse and fine adjustment - 1.25 N.A. condenser, with aperture and filter holder - 1W LED lighting, with adjustable brightness, with mains cable - Dust cover"

B-155 Monocular microscope, 4x, 10x, 40x, 100x, LED

112.B155

B-155 monocular biological microscope

Request a price

"Mode of observation: clear field of view. Eyepiece: WF10x/18 mm, fixed with a screw. Nose part: Quadruple ball bearing rotating nose part. Objectives: – High-contrast achromat 4x/0.10, with anti-fungal treatment – High-contrast achromat 10x/0.25, with anti-fungal treatment – High-contrast achromat 40x/0.65, with anti-fungal treatment – High-contrast achromat 100x/1.25 (oil/water), with anti-fungal treatment. Stage: mechanical, size: 125x116mm, X-Y movement range: 70x30 mm. Vernier scale on both axes, accuracy: 0.1mm. Focusing: Coaxial coarse and fine focusing mechanism with end stop to prevent contact between lens and specimen. Adjustable tension of the coarse focus knob. Condenser: Abbe N.A. 1.25, pre-centered, focusable, with iris diaphragm. Lighting: X-LED1 with white 1 W LED and brightness control. Color temperature: 6300 K. Multi-connector 100-240Vac/5Vdc external power supply"
